Product Description
PE series jaw crusher machine is usually used as primary crusher in quarry production lines, mineral ore crushing plants and powder making plants. It can be described as obbligato machine in mining, building construction, construction wastes crushing, Hydropower and Water Resource, railway and highway construction and some other industries.
Advantages
1. High stability and high reliability:
The movable jaw assembly adopts high quality steel castings and heavy eccentric shaft by forging processing. All this equipment ensures that the jaw crusher machine has the extraordinary stability. Compared with other the same specification crusher, we adopt the bigger and more durable eccentric shaft bearing so that it has higher bearing capacity to ensure its reliability.
2. Advanced Technology And Long Service Life:
With the world-class manufacturing processes, using digital components of advanced processing equipment, it can ensure that the machine parts precision. The selection of the most high-end material greatly enhances the compressive resistance and wears resistance and greatly prolongs the service life of the machine.
3. Simple Structure, Convenient Repair:
Through the improvement and optimization constantly, we increase the machine's performance at the same time the structure of the machine is simplified as well. The whole machine is more easy to operate and repair is more convenient and less downtime.
4. Good capacity and fine size.
Application
Various minerals and big materials medium crushing in metallurgy, building, highway, railway, water conservancy and chemical industries.
Suitable Material:Granite, marble, limestone, quartz stone, basalt , river pebbles, iron ore, copper ore etc.
Technical Parameters
| Model | Max feeding size
(mm) | Discharge opening
(mm) | Capacity (t/h) | Power
(kw) | Weight
(t) | Dimensions
(LxWxH)
(mm) |
| PE-150x250 | 125 | 10-40 | 1-3 | 5.5 | 0.6 | 720x660x850 |
| PE-200x300 | 180 | 15-50 | 2-6 | 7.5 | 1 | 910x750x990 |
| PE-200x350 | 180 | 18-70 | 3-10 | 11 | 1.3 | 1000x870x990 |
| PE-250x400 | 210 | 20-60 | 5-20 | 15 | 2.8 | 1300x1090x1270 |
| PE-400x600 | 340 | 40-100 | 16-60 | 30 | 7 | 1730x1730x1630 |
| PE-500x750 | 425 | 50-100 | 40-110 | 55 | 12 | 1980x2080x1870 |
| PE-600x900 | 500 | 75-200 | 60-200 | 75 | 20 | 2290x2290x2400 |
| PE-750x1060 | 630 | 80-140 | 115-330 | 110 | 29 | 2660x2430x 800 |
| PE-900x1200 | 750 | 95-165 | 220-450 | 110 | 52 | 3380x2870x3330 |
| PE-1000x1200 | 850 | 195-265 | 315-500 | 110 | 55 | 3480x3876x3330 |
| PEX-150x750 | 120 | 18-48 | 8-25 | 15 | 3.8 | 1200x1530x1060 |
| PEX-250x750 | 210 | 25-60 | 13-35 | 30 | 5.5 | 1380x1750x1540 |
| PEX-250x1000 | 210 | 25-60 | 16-52 | 37 | 7 | 1560x1950x1390 |
| PEX-250x1200 | 210 | 25-60 | 20-61 | 45 | 8.5 | 2140x1660x1500 |
| PEX-300x1300 | 250 | 20-90 | 16-105 | 75 | 11 | 2720x1950x160 |
